100kg 250kg 500kg 750kg 1000kg metal iron steel copper bronze aluminum scrap melting furnace industrial furnace
1. Brief Introduction of Medium Frequency Induction Melting Furnace:
Through long-term practical test, constant power (energy-saving) Intermediate frequency induction melting furnace has been widely praised among customers. What’s more, our melting furnace has made some improvements based on its original type, and its property is becoming more excellent.
2. Features of KGPS induction melting furnace:
a. High melting rate.
b. Good-quality molten steel, high casting product yield.
c. High power factor. During the machine’s operation, the power factor can reach over 97%.
d. No harm to the power gird.
e. Low power consumption, saving over 10% energy.
f. High start-up success rate. Under any load, the start-up success rate is 100%.
g. The main control panel adopts plug-in connector, easier maintenance.
h. Simple to install. Installation can be done by unprofessional workers very easily.
i. The melting furnace adopts series thyristor, making the SCR damage rate to a minimum.
3. Technical Parameter of Large Induction Melting Furnace:
| Model | KGPS-1T/800KW |
| Rated Power | 800kw |
| Rated Capacity | 1T |
| Matching transformer's capacity | 1000KVA |
| Voltage | 380V, 50/60HZ |
| MF Frequency | 1KHZ |
| Medium Voltage | 750V Phase |
| DC Voltage | 500V Phase |
| DC Current | 1600A Phase |
| Rated Temperature | 1800°C |
| Closed Loop Water Cooling Tower | LSN-80B |
4. Large Induction Melting Furnace Application:
(1) iron, pig iron, cast iron;
(2) steel, stainless steel, cast steel, carbon steel and bearing steel;
(3) gold, silver, platinum;
(4) copper, brass, bronze;
(5) aluminum, aluminum alloy;
(6) zinc, lead, tin, magnesium, nickel, titanium.
5. Certificates
